Description
PowerEdge R750 Rack Server Dubai
The Dell PowerEdge R750 Dubai is a high-performance enterprise-grade rack server designed to meet the rigorous demands of modern IT environments. With its robust architecture and advanced features, this server empowers businesses to optimize application performance, accelerate results, and tackle a variety of workloads, including database management, analytics, and Virtual Desktop Infrastructure (VDI).
Enterprise-Level Performance for Demanding Workloads
The Dell PowerEdge R750 Dubai is engineered to handle complex and intensive workloads effortlessly. Powered by 3rd Generation Intel® Xeon® Scalable processors, this dual-socket/2U rack server delivers exceptional processing capabilities to support innovative and emerging use cases.
Key Features:
- Memory Optimization: Up to 8 memory channels per CPU and support for 32 DDR4 DIMMs running at 3200 MT/s, ensuring fast and reliable data access.
- Enhanced Storage and I/O: PCIe Gen 4 technology and support for up to 24 NVMe drives enable significant throughput improvements.
- Thermal Management: Advanced cooling solutions, including Direct Liquid Cooling (optional), ensure stable operation under heavy power and thermal loads.
These features make the PowerEdge R750 Dubai ideal for workloads like:
- Database and Analytics
- High-Performance Computing (HPC)
- AI/ML environments
- Traditional Corporate IT
- Virtual Desktop Infrastructure (VDI)
Enhanced Operational Efficiency with Intelligent Management
Simplify and streamline IT operations with the Dell EMC OpenManage systems management portfolio. These tools provide an integrated and intuitive approach to managing complex infrastructures, helping IT teams focus on business growth rather than operational bottlenecks.
Highlights of OpenManage Systems Management:
- Comprehensive Visibility and Control: Features such as built-in telemetry streaming, thermal management, and a RESTful API with Redfish provide seamless server management.
- Intelligent Automation: Allows for collaboration between system automation and human inputs, boosting productivity.
- Effortless Updates and Configuration: Integrated tools enable smooth, zero-touch updates and configurations for minimal downtime.
- Full-Stack Integration: Compatibility with leading platforms such as Microsoft, VMware, ServiceNow, and Ansible ensures easy integration into existing IT ecosystems.
Secure and Resilient Design for Data Protection
The PowerEdge R750 Dubai incorporates a cyber-resilient architecture, embedding security at every stage of its lifecycle to safeguard your data and infrastructure.
Key Security Features:
- Secure Booting: Anchored by cryptographically trusted processes and a silicon root of trust.
- Firmware Protection: Digitally signed firmware ensures system integrity.
- System Lockdown: Prevents unauthorized configuration or firmware changes.
- System Erase: Enables quick, secure deletion of data from storage media, including SSDs and system memory.
Built for Modern Data-Centric Workloads
The Dell PowerEdge R750 Dubai is a powerhouse designed to address evolving business needs by delivering:
- Compelling performance for data-intensive operations.
- High-speed memory for enhanced computational tasks.
- Extensive storage capacity to meet growing data requirements.
- Increased bandwidth for faster processing and I/O.
Ideal Applications
- Traditional Corporate IT
- Database Management and Analytics
- Virtual Desktop Infrastructure (VDI)
- Artificial Intelligence/Machine Learning (AI/ML)
- High-Performance Computing (HPC)
Elevate your IT infrastructure with the Dell PowerEdge R750 Dubai— a server built to meet the challenges of today and the innovations of tomorrow.
Features & Design
Your innovation engine
The Dell EMC PowerEdge R750 Dubai, powered by 3rd Generation Intel® Xeon® Scalable processors, is the optimal rack server to address application performance and acceleration.
- Supports 8 channels per CPU, up to 32 DDR4 DIMMs at 3200 MT/s DIMM speed
- Address substantial throughput improvements with PCIe Gen 4 and up to 24 NVMe drives
- Ideal for traditional corporate IT, database and analytics, VDI, and AI/ML and Inferencing
- Optional Direct Liquid Cooling support to address high wattage processors
Technical Specifications
Processor
- Up to two 3rd Generation Intel® Xeon® Scalable processors, with up to 40 cores per processor
- Direct Contact Liquid Cooling (DCLC) option: Yes
Operating System
- Canonical Ubuntu Server LTS
- Microsoft Windows Server with Hyper-V
- Red Hat Enterprise Linux
- SUSE Linux Enterprise Server
- VMware ESXi
Chipset
Intel C620 series chipset
Accelerators
Up to two double-width 300 W, or four single-width 150 W, or six single-width 75 W accelerators
Memory
DIMM Speed
Up to 3200 MT/s
Memory Type
RDIMM, LRDIMM, NVDIMM, Intel Persistent Memory 200 series (BPS)
Memory Module Slots
32 DDR4 DIMM slots
Maximum RAM
RDIMM 2 TB, LRDIMM 8 TB, NVDIMM 128 TB, Intel Persistent Memory 200 series (BPS) 8 TB
Storage
Front Bays
- Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB
- Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB
- Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB
- Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.64 TB
Rear Bays
- Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB
- Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB
Storage Controllers
Internal Controllers
PERC H745, HBA355I, PERC H345, PERC H755, PERC H755N
External Controllers
PERC H840, HBA355E
Software RAID
S150
Internal Boot
- Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSDs 240 GB or 480 GB
- Boot Optimized Storage Subsystem (BOSS-S1):HWRAID 2 x M.2 SSDs 240 GB or 480
- Internal Dual SD Module or USB
Security
- Cryptographically signed firmware
- Secure Boot
- Secure Erase
- Silicon Root of Trust
- System Lockdown (requires iDRAC9 Enterprise or Datacenter)
- TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Management
- iDRAC9
- iDRAC Service Module
- iDRAC Direct
- Quick Sync 2 wireless module
Consoles
- OpenManage Enterprise
- OpenManage Power Manager plugin
- OpenManage SupportAssist plugin
- OpenManage Update Manager plugin
Mobility
OpenManage Mobile
Tools
- RACADM CLI
- iDRAC RESTful API with Redfish
- IPMI
- System Update Utility
- Update Catalogs
OpenManage Integrations
- BMC Truesight
- Microsoft System Center
- Red Hat Ansible Modules
- VMware vCenter and vRealize Operations Manager
OpenManage connections
- IBM Tivoli Netcool/OMNIbus
- IBM Tivoli Network Manager IP Edition
- Micro Focus Operations Manager
- Nagios Core
- Nagios XI
Power Supplies
- 700 W Titanium AC/240 V Mixed Mode
- 800 W Platinum AC/240 V Mixed Mode
- 1100 W Titanium AC/240 V Mixed Mode
- 1100 W DC -48 – -60 V
- 1400 W Platinum AC/240 V Mixed Mode
- 1800 W Titanium AC/240 V Mixed Mode
- 2400 W Platinum AC/240 V Mixed Mode
- 2800 W Titanium AC/240 V Mixed Mode
- Hot plug power supplies with full redundancy option
Ports
Network Options
2 x 1 GbE LOM and 1 x OCP 3.0 (x8 PCIe lanes) (optional)
Front Ports
- 1 x Dedicated iDRAC Direct micro-USB
- 1 x USB 2.0
- 1 x VGA
Rear Ports
- 1 x USB 2.0
- 1 x USB 3.0
- 1 x Serial (optional)
- 2 x RJ-45
- 1 x VGA (optional for liquid cooling configuration)
Internal Ports
1 x USB 3.0
Slots
PCIe
Up to 8 x PCIe Gen4 slots (up to 6 x16) with support for SNAP I/O modules
Video Card
1 x VGA (optional for liquid cooling configuration)
Bezel
Optional LCD bezel or security bezel
Form Factor
2U rack server
Dimensions & Weight
Height
86.8 mm (3.41 inches)
Width
482.0 mm (18.97 inches)
Depth
- 758.29 mm (29.85 inches) – without bezel
- 772.13 mm (30.39 inches) – with bezel
Weight
31.8 kg (70.10 lbs)
Rack Support
- ReadyRails II sliding rails with optional cable management arm (CMA) and strain relief bar (SRB) for 4-post racks.
- Combo (Drop-in/Slide-in) rails with optional CMA and SRB for 4-post racks.
- ReadyRails static rails for 4-post and 2-post racks.
