Description
Horion 86M3A 86-inch Super Interactive Flat Panel Dubai
The Horion 86M3A 86-inch Super Interactive Flat Panel multimedia touch screen monitor is an 86-inch Interactive Flate Panel, 4K UHD Premium Panel for smoother writing, a new 1mm pen, easy to write, fine detail. This Horion 86M3A 86-inch Super Interactive Flat Panel has split-screen use. two screens at the same time.The Horion 86M3A 86-inch Super Interactive Flat Panel support two people touch simultaneously using Pen & Finger.
Horion 86M3A 86-inch Super Interactive Flat Panel is Equipped with an OPS interface and a scalable dual system Android 8.0 & Windows 10,a dual USB interface with dual system compatibility and a dual network interface for device switching and Equipped with Android 8.0 Smart OS and a unique user interface design. Horion 86M3A 86-inch Super Interactive Flat Panel has 3GB internal cache + 32GB internal storage, for faster-operating speeds. The exterior features four minimalist arc-shaped edges; the WIFI and Bluetooth antennas adopt a forward, hidden design. Front-disassembly, high-precision, infrared touch frame with touch precision of ±1mm and touch the height of 2.0mm, highly sensitive, supports 20 touchpoints. Horion 86M3A 86-inch Super Interactive Flat Panel high-performance writing software that supports single and multi-point writing with improved writing effects with the pen, so that users can annotate on any interface and any channel.
Horion 86M3A 86-inch Super Interactive Flat Panel Features:
- Create a powerful presentation from your finger-tips
- Write, draw or erase instantly on the digital whiteboard using Smart Touch Pen
- Eliminate connectivity problems with devices and projector
- Record discussion notes in one-click to USB, email, or mobile phone
- Encourage collaborative interaction in learning or working environment
Horion 86M3A 86-inch Super Interactive Flat Panel Specifications:
| Model | 86M3A |
| Dimension | 86″ |
| Display | |
| Backlight Type | D-LED |
| Resolution | 3840*2160 (UHD) |
| Brightness | 400cd/m2 |
| Contrast Ratio | 1200:1 |
| Response Time | 8ms |
| Pixel Pitch | 0.4935 m m*0.4935m m |
| Refreshing Frequency | 60Hz |
| Viewing Angle | 178°(H) / 178°(V) |
| Saturation(x% Ntsc) | 65% |
| Visable Area | 1895.04mm*1065.96mm |
| Chromaticiy | 1.07 B(10 bit) |
| Life Time | 30,000 hrs |
| System Properties | |
| CPU Architecture | ARM A73+A53 |
| CPU Working Frequency | 1.5G Hz |
| CPU Core | Quad Core |
| GPU | Mali-G51 |
| RAM | 3GB |
| ROM | 32 GB |
| Power | |
| Voltage | 100 V -‘ 240 V/AC, 50/60 Hz |
| Maximum Power (Without Ops) | 440W |
| Standby Power | <0.5W |
| AC Input | * 1 |
| Structure | |
| Net Weight | 76Kg+1.5Kg |
| Gross Weight | 98Kg+1.5Kg(Heavy Carton) |
| Product Size (L*W*K) | 1995.2mm*111.9mm*1166.3mm |
| Package Size (L*W*H) | 2140mm*280mm*1340mm(Heavy Carton) |
| Vesa | 4-M8 Screw Hole 700mm*400mm |
| Housing Material (Front/Back) | Aluminum/Metal Plate |
| Housing Color (Front/Back) | Deep Gun(White)/Black |
| Touch System | |
| Touch Type | Infrare Touch Frame |
| Glass Type | 4mm AG Tempered Glass |
| Respond Time | <10ms |
| Touch Accuracy | +1mm |
| Input Mode | Finger/Writing Pen |
| Operating System | |
| Support Multi Touch Control | Multi-point: Windows 7/8/10, Android, Linux, Single-point: Windows XP, Mac OS X, Chrome |
