Description

NEWROCK OM50G IP-PBX Dubai

The Newrock OM20G IP PBX simply connects PSTN to analog terminals, and -based SIP trunks to SIP terminal, and uses VoIP to enable calls between different offices over the internet or VPN. The Newrock OM20G IP PBX Dubai supports up to 30 concurrent calls, the hi-tech device uses SSH and HTTPS security protocols which enable easy remote access, brute-force password cracking prevention, cipher-text data storage, access whitelist, and system-log backup thus securing your files from any malicious cyber attacks. Enjoy noise-free conversations courtesy of the award-winning Echo Cancellation technology that has been embedded in the Newrock OM50G IP PBX Dubai. The Newrock OM50G IP PBX Dubai is based on SIP v2 (RFC 3261) and works perfectly with most of the SIP platforms such as  Cisco CallManager/CUCM, Broadsoft, Microsoft Skype for Business (Lync), –  Huawei IMS, and Asterisk/Elastix, thus boosting productivity in your office.

NEWROCK OM50G IP-PBX FEATURES

AUTOMATED – PROVISIONING – TFTP/HTTP/HTTPS

The technologically advanced Newrock OM50G IP PBX Dubai has the ability to deploy an information technology or telecommunications service by using embedded pre-defined procedures that are carried out electronically without requiring any human intervention, thus making it very reliable and convenient. Auto-provisioning not only allows remote and central management of device configuration and firmware upgrades but also enables you to cut down any maintenance costs incurred during deployment since it enhances remote device management. It also eliminates the potential risk of loss of data and data intrusion by providing configuration file backup and data encryption on transmission.

ALWAYS STAY IN TOUCH WITH YOUR CUSTOMERS

The Newrock OM50G IP PBX Dubai is equipped with advanced features such as remote extension, call forking to your mobile phone, and call-back, ensuring that you never miss out on important business calls whether you are traveling abroad, working from home, or in your office.

IMPROVED CALL ANSWER RATES

The Newrock OM50G IP PBX Dubai can not only bypass voice menus in order to deliver calls from VIP customers to the agents directly, but also provide 24/7 live answering service to customers, and direct the incoming calls to the extension or cell phone of the right person through configurable voice menus in business/non-business hours and holidays.

CHEAPER TELECOMMUNICATION COSTS

With all the IP remote – calling functions installed, the Newrock OM50G IP PBX Dubai enables remote workers to communicate all through, regardless of their locations, at a pocket – friendly price, thus maximizing productivity at work. IP – Remote calling function enables the user to make international calls and long-distance calls freely toll – free, at an affordable cost. The Newrock OM50G IP PBX Dubai is equipped with advanced routing capabilities, enabling it to route calls automatically depending on the type of call. When combined with New Rock’s WeWei® softphone App and NeeHau™ SoftConsole, the Newrock OM50G IP PBX Dubai enhances the communication experience between you and your customers.

EXCELLENT AUDIO QUALITY

The high performing Newrock OM50G IP PBX Dubai offers users distraction-free communication courtesy of the inbuilt industry-leading Acoustic Echo Canceling Technology(G.168 – 2004), Adaptive Jitter Buffer, Voice Activity Detection, and Comfort Noise Generation that deliver superior High Definition sound quality devoid of extraneous noises. This makes it possible to enjoy fluent phone conversations without any distractions.

TECHNICAL REPORT) TR – 069

This is a technical specification of the Broadband Forum that defines an application layer protocol for remote management of customer-premises equipment (CPE) connected to an Internet Protocol (IP) network. The TR-069 embedded in the Newrock OM50G IP PBX Dubai uses the CPE WAN Management Protocol (CWMP) to provide support for functions such as auto-configuration, software or firmware image management, software module management, status and performance management, and diagnostics. The CPE WAN Management Protocol is a bidirectional SOAP – and HTTP-based protocol, and provides the communication between a CPE and auto-configuration servers (ACS). The protocol addresses the growing number of different Internet access devices such as modems, routers, gateways, as well as end-user devices which connect to the Internet, such as set-top boxes, and VoIP devices such as the Newrock OM50G IP PBX Dubai.

SIP – BASED CONNECTION

You can easily connect your Newrock OM50G IP PBX Dubai to your IP PBX System or direct to a VoIP service provider in order to enjoy seamless conference calls. The Newrock OM50G IP PBX Dubai is based on SIP v2 (RFC 3261) and works perfectly with most of the SIP platforms such as  Cisco CallManager/CUCM, Broadsoft, Microsoft Skype for Business (Lync), –  Huawei IMS, and Asterisk/Elastix that currently exist in the market.

CLOUD MANAGEMENT

New Rock provides a reliable and secure cloud service to deliver connectivity to its users at cheaper maintenance costs while enhancing operation and maintenance efficiency. The cloud service on the internet enables customers to gain direct access to Newrock devices available in private networks such as IP-PBXs, audio gateways, and IP phones, therefore allowing simple remote maintenance and management of New Rock devices. This kind of cloud service is specifically designed to meet the needs of large-scale installation, configuration, and maintenance and operation. Auto-provisioning and configuration backup, online update, real-time monitoring and alert enable users to achieve efficient operation and maintenance, thus maximizing productivity in organizations.

 FIRMWARE UPGRADEABLE

You can easily update the operating system on your Newrock OM50G IP PBX Dubai so as to improve its functionality and enhance user experience. Upgrading firmware also fixes any existing bugs and protects you from any kind of software malfunctions and vulnerabilities. To update your gadget’s firmware, type your gateway’s IP address into your web browser and enter your login information. Then locate the Firmware or Update section and download the latest firmware update on your Newrock OM50G IP PBX Dubai system’s manufacturer’s website. Finally, upload the update and reboot the telephony system.

Why the OM50G IP PBX Dubai?

• The Newrock OM50G IP PBX Dubai is equipped with a built-in analog gateway module and storage capacity for recording, FoIP and voicemail
• Advanced mobile extensions which keep you connected anywhere and any time, ensuring that you do not miss out on any important business calls
• Enjoy advanced call features such as click – to – dial , call history and call recording
• XML/HTTP-based RESTful API for third-party applications
• Plug & Play feature for Newrock IP phones
• Remote Access via the Newrock Cloud Management with the Newrock or Third – Party Element Management Systems (TR-069 SNMP)
• Add – on middle-ware for hospitality applications
• SIP-based trunks enable Headquarters and branch offices to be in constant communication.

NEWROCK OM50G IP-PBX SPECIFICATIONS

• CPU : Dual core, 880MHz
• RAM : 256MB
• Flash : 16MB
• Internal USB flash drive : 16GB
• Max. Concurrent calls : 30
• Max. Analog extensions : 12
• Maximum IP extensions : 50
• Maximum analog trunks : 6
• Maximum IP trunks : 62
• Dimensions(H*W*D) : 41 × 286 × 161(mm)
• Net weight : 1.2kg
• DC power input voltage : 12VDC/1.5A
• Power consumption : 18W
• Mounting : desktop, rack
• Operating conditions : temperature : 0 – 40°C, Humidity :10 – 90% (non – condensing)
• Storage conditions : Temperature : -40°C to 70°C, Humidity : 5 – 90% (non – condensing)

OTHER FEATURES

• Log Management :  8 – level logs, Syslog, internal USB flash drive (16GB)
• Data capture :   port capture, packet capture
• Status and statistic : call status and history, Device status monitoring and ISDN status monitoring
• Configuration : Bulk Import/export. Resettling to the factory default.
• Encryption : encrypted password/PIN
• ISDN maintenance : BERT, Near and loop back, ISDN – D & ISDN – B channel
• Upgrade : Firmware upgrade via Web GUI or Auto provisioning

PROTOCOLS

• Call Control : SIP/UDP and SIP/TCP(RFC3261), IMS(3GPP), MGCP(RFC3435)
• Network : SSH, HTTP, HTTPS, DHCP/PPPoE client, Radius, DNS( A/SRV record), STUN

MEDIA PROCESSING

• Caller ID : Bellcore/Telcordia, ETSI, BT, DTMF, G.711(a/u), G.729a, G.722, G.722.2* Roadmap feature
• DTMF : in – band audio, RFC2833, SIP – INFO
• Hook – flash : Local Processing, RFC2833, SIP – INFO
• Fax over IP :
  • T.38, G.711 pass through
  • T.38 compliant Group 3 Fax
  • Relay
  • Maximum frame rate of 33,600bps(T.38)
  • Disconnect modes : Polarity reversals, Busy tone Detection, Loop current
• QoS : DiffServ, TOS, 802.1P/Q VLAN tagging
• Voice – quality Enhancement : Echo cancellation (G.168 – 2004), Jitter Buffer, Silence suppression(VAD, CNG), PLC
