YEASTAR TG 100 GSM Gateway Dubai

Reviews

YEASTAR TG 100 GSM Gateway Dubai

Revel in unlimited 2 – way communications using the Yeastar TG 100 GSM Gateway which allows you to make VoIP to GSM and GSM to VoIP calls. The user friendly Yeastar TG 100 GSM Gateway is a cheap way to enjoy endless communications, thanks to its advanced features such as the Bulk SMS Service which allows you to send thousands of messages to clients at once. The Yeastar TG100 GSM Gateway comes with incorporated modern call features which work to accord you an excellent communication experience at a cheap price.

Ask for Quote & Get Low Price

Description

YEASTAR TG 100 GSM Gateway Dubai

YEASTAR TG 100 GSM Gateway is equipped with 1 GSM Port and uses a number of voice codecs including G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, and Speex to deliver crisp and clear audio. It also uses Echo Cancellation to filter out any background noises which may pose as distractions during communication. The premium Gateway boasts of a strong frequency of 850/900/1800/1900 MHz and a WCDMA Frequency of 850/1900 MHz, 850/2100 MHz, 900/2100MHz. Its compatibility with major IP PBX and softswitch brands (Asterisk, MS Lync, Trixbox, Elastix, FreeSWITCH, 3CX) makes it a highly efficient device.

YEASTAR TG100 GSM GATEWAY FEATURES

EASY TO USE

The Yeastar TG 100 GSM Gateway Dubai boasts of a friendly GUI which accords the user an easy experience in installing and operating it. It comes with a simple and Web – based configuration which saves the user from any delays. One therefore does not require any technical skills in handling the magnificent Gateway.

INTEROPERABILITY

The highly versatile Yeastar TG 100 GSM Gateway is SIP – based, therefore offering maximum compatibility with various leading professional PBX platforms such as , Elastix, Trixbox, FreeSWITCH, 3CX) Lync Server and BroadSoft, among many others.

BULK SMS SERVICE

In most cases in business the winning formula lies in enhancing customer relations by empowering your staff. The Bulk SMS Service feature  incorporated into the Yeastar TG 100 GSM Gateway enables your workers to send multiple text messages to customers, branded with a sender ID which is usually the name of your organization. The feature does not limit you to sending messages locally since you can also send messages internationally at a low affordable price.

MOBILE TRUNKINGS

The Yeastar TG 100 GSM Gateway allows you to add GSM/WCDMA trunkings so as to expand your communication capabilities. This enables a user to make unlimited number of calls to different mobile networks at a cheap price thus boosting productivity at work.

BUDGET – FRIENDLY

The Yeastar TG 100 GSM Gateway enables you to cut down costs incurred in communication courtesy of its efficient call features such as Least Cost Routing(LCR) an the Bulk SMS service which allows you to send numerous messages at once.

SUPERB AUDIO QUALITY

The Yeastar TG 100 GSM Gateway is both narrowband and wideband – enabled, delivering cyrstal clear audio devoid of distractions. The powerful Gateway supports a number of audio codecs including, G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, and Speex which is a free software patent – free audio compression format which is built specially for production of human speech. It also incorporates ITU-T G.168 LEC type of the award winning Echo Cancellation technique which accurately filters out any background noise while maintaining clear and audible sounds even in busy and noisy environments.

G168 ECHO CANCELLATION

The excellent Yeastar TG 100 GSM Gateway uses G168 Echo Cancellation to filter out any background and surrounding noises that may act as distractions whenever the GoIP user is making any communications.

ADVANCED CALL FEATURES

The Yeastar TG100 GSM Gateway comes with incorporated modern call features which work to accord you an excellent communication experience at a cheap price. Some of the features include:

Least Cost Routing (LCR) : Least Cost Routing is a way of finding a cheaper way to route phone calls during communication. A user simply analyses, selects and directs the path of outbound and inbound communications traffic while choosing the path which delivers the best call rates.

Calling Type : Yeastar TG 100 GSM Gateway presents two – way phones calls including, termination and origination.

  • Termination – this type of calls are made from the VoIP to the GSM Gateway
  • Origination : a user makes calls from the GSM to the VoIP Gateway.

THE BACK UP FEATURE

The Yeastar TG 100 GSM Gateway comes with an added backup plan feature which comes in handy when the landline network goes down. This saves you from unnecessary delays during communication, thus maximizing productivity at work.

SIP – COMPLIANT GATEWAY

The Yeastar TG 100 GSM Gateway is based on SIP v.2.0 (RFC3261) so that you can easily plug and play your phone without any configurations. Once the phone is connected to the network and powered on, initialization starts automatically, after which the phone is up and ready for use. It therefore works perfectly with major PBX platforms and softswitch brands including, Asterisk, MS Lync, Trixbox, Elastix, FreeSWITCH, 3CX.

RICH QoS ABILITIES

The Yeastar TG 100 GSM Gateway saves you from unnecessary delays when there are high volumes of traffic in the network being used. It simply prioritizes traffic so that more important traffic can pass first, resulting in an overall performance improvement for critical network traffic.

AUTOMATED – PROVISIONING – TFTP/HTTP/HTTPS

The technologically advanced Yeastar TG 100 GSM Gateway has the ability to deploy information technology or telecommunications service by using embedded pre-defined procedures that are carried out electronically without requiring any human intervention, thus making it very reliable and convenient.

HIGH SECURITY LEVELS

Securing your data and files from any malicious cyber attacks and unauthorized access by users, devices and applications is key. The Yeastar TG 100 GSM Gateway uses a number of leading security protocols to ensure you never lose important files and data.

Why the Yeastar TG 100 GSM Gateway?

  • Calling Type – termination (VoIP to GSM), origination (GSM to VoIP)
  • Callback function
  • SMS sending and receiving (Web interface)
  • LCR (least cost routing)
  • Simple web based configurations
  • Pocket – friendly – Save phone bills tremendously with mobile-to-mobile calls and LCR.
  • Back up – Work as a cost-effective backup when the landline network goes down.
  • Easy to install – Everything can be easily set up in the Web based management interface.
  • Easy to integrate – High compatibility with major IP PBX and softswitch brands (Asterisk, MS Lync, Trixbox, Elastix, FreeSWITCH, 3CX)

YEASTAR TG 100 GSM GATEWAY SPECIFICATIONS

Model TG 100
Number of Ports 1
GSM Frequency** 850/900/1800/1900 MHz
WCDMA Frequency** 850/1900 MHz, 850/2100 MHz, 900/2100 MHz
4G Data
4G LTE Band** Don’t support 4G LTE
Protocol SIP, IAX2
Antenna Splitter (4 in 1)
Transport UDP, TCP, TLS, SRTP
Voice Codec G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, Speex
DTMF Mode RFC2833, SIP Info, In-band
Echo Cancellation ITU-T G.168 LEC
Calling Type Termination (VoIP to GSM/WCDMA), Origination (GSM/WCDMA to VoIP)
Console Port
Network Protocol FTP, TFTP, HTTP, SSH
LAN 1 10/100 Mbps Ethernet Interface
NAT Traversal Static NAT, STUN
Network DHCP, DDNS, Firewall, OpenVPN, Static IP, QoS, Static Route, VLAN
Operation Range 0°C to 40°C, 32°F to 104°F
Power Supply DC 12V, 1A
Storage Range -20°C to 65°C, -4°F to 149°F
Dimensions (L × W × H) (mm) 213 x 160 x 44
Humidity 10-90% non-condensing
