Meraki MS250-48FP Dubai

The Meraki MS250-48FP Dubai series switches provide reliable access switching ideal for deploying in branches and small campuses.

Add to quote

Ask for Quote & Get Low Price

Description

Meraki MS250-48FP Network Switch Dubai

The Meraki MS250-48FP Dubai is a 24-port cloud-managed stackable enterprise-class access switch with four SFP+ uplinks, support for redundant power supplies for mission critical environments, and IP routing. The MS250 family includes integrated client and layer 7 application visibility, remote troubleshooting tools like live packet capture and cable test. The MS250 family is 100% cloud-managed via the intuitive, browser-based Meraki dashboard, and includes a rich, out-of-the-box feature set without additional cost and complexity.

The Meraki MS250-48FP Dubai series switches provide reliable access switching ideal for deploying in branches and small campuses. With stacking capabilities and 10G SFP+ uplinks on every model, redundancy and performance are guaranteed. This family also supports redundant, field-replaceable power supplies for mission critical networks.

Meraki MS250-48FP Dubai is built from the ground up to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches.

The Meraki MS250-48FP Dubai is managed through an elegant, intuitive cloud interface, rather than a cryptic command line. To bring up a Meraki switch, just plug it in; there’s no need for complicated configuration files, or even direct physical access to the switch.

Cisco Meraki MS250-48FP Key Features:

Gigabit access switching with 24- and 48- port models and optional PoE+ support
4 x 10G SFP+ uplink interfaces on all models
Dual stacking interfaces with up to 80G of bandwidth
Support for field replaceable, redundant power supplies
Non-blocking switch backplane with up to 176 Gbps of switching capacity
6 configurable QoS queues for converged voice, video, and data applications
Up to 740 watt PoE budget with PoE+ support and dynamic power allocation for powering APs, phones, cameras, and other PoE-enabled devices
Low power consumption, quiet acoustic design, and shallow rack depth options, enabling flexible deployment in wiring closets as well as offices and classrooms
Integrated mounting brackets for rack mounting
Lifetime hardware warranty and advanced replacement at no additional cost

Technical Specs

Actual Weight

12.80 lb(s)
Connectivity

# Ports : 48

# Ports : 4
Contents

Switch, power cord, power supply, mounting kit, documentation
General

Chassis Form Factor : 1U Rackmount

Color : Silver

Warranty Period : Limited lifetime
General Information

Switching capacity : 176Gbps
Stacking bandwidth : 80G (dual interface)
MAC forwarding entries : 32K
Forwarding rate : 127.98Mpps
Physical Dimensions

1.7″h x 19.1″w x 23.4″d
Ports/Connectors

I/O:
(48) GbE RJ45
(4) 10GbE SFP+
(2) stacking ports
(1) Power in
Power

# Power Supplies Installed : 1
Power Notes

Idle / Full Load Power : 25 / 874 W
Available PoE+ Power : 740W
Power Supply : Hot-swappable
Supported Power Supply (included) : (1) 1025W PSU
Protocols

Networking Protocol : 10 Gigabit Ethernet

Networking Protocol : PoE+

Networking Protocol : IGMP

Networking Protocol : OSPF

Networking Protocol : Gigabit Ethernet

Remote Management Protocol : HTTP

Remote Management Protocol : SNMP

Routing Protocol : IGMP

Routing Protocol : OSPFv2

Routing Protocol : VRRP
Shipping Weight

19.84 lbs
Standards

Compliant Standards : FCC

Compliant Standards : RoHS
UNSPSC

43222612
Warranty – Labor

Limited Lifetime
Warranty – Parts

Limited Lifetime
