Tplink TL-SM5110LR Dubai

Reviews

Tplink TL-SM5110LR Dubai

Tplink TL-SM5110LR Dubai is compatible with switches with 10G SFP+ ports, like JetStream TL-SG3428X, TL-SG3428XMP, and more.

Ask for Quote & Get Low Price

Description

Tplink TL-SM5110LR Transciever Dubai

The Tplink TL-SM5110LR is designed to extend transfer distances based on 10Gbps Ethernet connectivity. It is a 10GBASE-LR high performance 1310 nm single-mode SFP+ transceiver. It supports full duplex, 10G Ethernet connections up to 10 km with 9/125µm fiber cables respectively.

Features

  • Single-mode SFP+ LC Transceiver
  • Tplink TL-SM5110LR is hot-pluggable with maximum flexibility
  • Supports Digital Diagnostic Monitoring (DDM)
  • Compatible with 10G Small Form Pluggable Multi-Source Agreement (SFP+ MSA)
  • Tplink TL-SM5110LR is compatible with switches with 10G SFP+ ports, like JetStream TL-SG3428X, TL-SG3428XMP, and more.

Technical Specs

PACKAGE CONTENTS
Package Contents
  • 10G SFP+ Module TL-SM5110-LR
  • Installation Guide
HARDWARE FEATURES
DDM Yes
SFP-MSA Yes
Hot Swappable Yes
TRANSCEIVER
Standards and Protocols IEEE 802.3ae, TCP/IP
Wave Length 1310 nm
Power Supply 3.3V
Fiber Type 9/125um Single-Mode
Max. Cable Length 10 km
Data Rate 10 Gbps
Port Type LC Duplex
Safety & Emission FCC, CE
Environment
  • Operating Temperature : 0–70 °C (32–158 °F)
  • Storage Temperature : -40–85 °C ( -40–185 °F)
  • Operating Humidity : 10–90% RH, Non-Condensing
  • Storage Humidity : 5–90% RH, Non-Condensing
