Qnap TS-569 Pro Dubai

The Qnap TS-569 Pro Dubai supports SMB/CIFS, NFS and AFP protocols for file sharing across Windows, Mac, Linux/UNIX networks.



Ask for Quote & Get Low Price

Description

Qnap TS-569 Pro Dubai

The  for SMBs from QNAP is an all-in-one NAS server with exceptional performance that can meet the storage requirements of modern SMB IT environments. It features a secure cross-platform file sharing for Windows, Mac and Linux/UNIX users. The NAS server also  It has a well-rounded set of backup solutions, which helps critical business information to be safely protected against unexpected data loss. The NAS server is an ideal shared storage solution for virtualized and clustered environments. It is VMware-ready and Citrix-ready certified. This also has proven compatibility with Microsoft Hyper-V environments.

The intuitive MyCloudNAS service simplifies the process of publishing content present on the Turbo NAS over the Internet and helps you create a private cloud in a few simple steps. The mobile app QMobile provides iOS or Android mobile device users with a convenient way to access the Turbo NAS live, on the go.

Deploying an appropriate IT environment with a reliable, affordable and expandable storage solution is very critical for any business. The ability to securely store, share and back-up digital assets has become one of the most important tasks for an SMB IT administrator. Choosing the right option will significantly enhance business productivity and offer a reliable disaster recovery solution in today’s times, when downtime of any type affects profitability. The Qnap TS-569 Pro Dubai is an all-in-one server that meets the storage requirements of modern businesses and workgroups that face the challenge of finding a robust storage solution that can scale with the exponential increase in digital content.

Features:

Cross-platform Sharing with Antivirus

The Qnap TS-569 Pro Dubai supports SMB/CIFS, NFS and AFP protocols for file sharing across Windows, Mac, Linux/UNIX networks. Your accounts and shared folders can be created via a user-friendly web based interface without IT expertise. The integrated antivirus solution for the Turbo NAS ensures business stability. It offers detection against the latest viruses, malware, worms and Trojan horses.

Windows Active Directory (AD) and LDAP Directory Service

The Windows AD and Lightweight Directory Access Protocol (LDAP) is a directory service feature that enables you to retrieve user accounts from Windows AD or LDAP based directory server to the Turbo NAS. This reduces time and effort in setting up a new account. You can use the same login name and password to access the Turbo NAS.

Shared Folder Aggregation

You can access the shared folders of other servers on Microsoft Networking through the “portal folder” on the Qnap TS-569 Pro Dubai. This saves the time and effort in logging in multiple servers one by one.

ISO File Archiving and Sharing

With the Qnap TS-569 Pro Dubai you can mount ISO images of CD and DVD discs as network shares for data archiving, storage and sharing. This saves the space for storing the physical discs and reduces the risk of data loss caused by disc wear and tear. It also enhances the efficiency of data sharing on business network.

Advanced Folder Permissions

You can configure folder/subfolder access to the Qnap TS-569 Pro Dubai with advanced folder permissions. With this feature enabled, you can manage the folder permissions from Microsoft Windows or the web-based management interface of the Turbo NAS easily.

Secure Measures for Data Storage and Access

•Policy based Unauthorized IP Blocking:
You can allow, deny or auto block specified IP address or network domain which attempt to connect to the Turbo NAS via SSH, Telnet, HTTP(S), FTP, Samba or AFP.

QNAP TS-569 Pro Specs

Hardware
CPU Intel Atom 2.13 GHz Dual-Core Processor
DRAM 1 GB RAM (expandable RAM, up to 3 GB)
Flash Memory 512 MB DOM
Hard Drive 5x 3.5″ (88.89 mm) SATA 6 GBps, SATA 3 GBps hard drive or 2.5″ (63.49 mm) SATA, SSD hard drive
Hard Disk Tray 5x hot-swappable and lockable tray
LAN Port 2x Gigabit RJ-45 Ethernet ports
LED Indicators Status, LAN, USB, eSATA, Power, HDD 1, HDD 2, HDD 3, HDD 4, HDD 5
USB 2x USB 3.0 ports (back: 2)
5x USB 2.0 ports (front: 1 ; back: 4)
Supports USB printer, pen drive, USB hub, USB UPS and more
eSATA 2x eSATA ports (back)
Performance Reading: 221.8 MBps
Writing: 220.8 MBps
Buttons System: Power button, USB one touch backup button and reset button
LCD Panel Mono-LCD display with backlight
Enter and select buttons for configuration
Supply Type System warning
Form Factor Tower
Sound Level Without HDD installed: 34.3 dB
Stand by: 34.3 dB
In operation: 35.0 dB
(with 5x 500GB HDD installed)
Power Consumption Sleep mode: 29.1 W
In operation: 48.5 W
Power-off (in WOL mode): 1 W
(with 500GB HDD installed)
Power Supply Input: 100 – 240 V AC, 50 – 60 Hz
Output: 250 W
Secure Design K-lock security slot for theft prevention
VGA Reserved VGA interface for maintenance
Fan 1x 4.72″ (12 cm), 12 V DC quiet cooling fan
Software
Operating System Embedded Linux
Supported Operating System Windows XP, Vista, Windows 7 (32/64-bit), Windows Server 2003/2008 R2
Apple Mac OS X
Linux and UNIX
Supported Web Browsers Microsoft Internet Explorer 8, 9
Mozilla Firefox 8, 9, 10
Apple Safari 4, 5
Google Chrome
Language Support Chinese (Traditional and Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish
File System Internal Hard Drive: EXT3, EXT4
External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+
Networking TCP/IP (IPv4 and IPv6: Dual stack)
Multiple Gigabit NICs with jumbo frame
-Failover
-Multi-IP settings
-Port trunking/NIC teaming (Modes: Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb)
Service binding based on network interfaces
Virtual LAN (VLAN)
DHCP client, DHCP server
Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP and SMSC
UPnP and bonjour discovery
USB Wi-Fi adapter support
Backup Solution Real-Time Remote Replication (RTRR)
-Works as both RTRR server and client with bandwidth control
-Real-time and scheduled backup
-Encryption, compression, file filter and transfer rate limitation
Block-Level Remote Replication
-Works as both Rsync Server and client with bandwidth control
-Encrypted replication between QNAP NAS servers
One touch backup (import/export) via USB
Desktop backup by QNAP NetBak replicator for Windows
Apple Time Machine support with backup management
Data backup to multiple external storage devices
Data backup to Cloud Storage (Amazon S3, ElephantDrive and Symform)
Security IP Filter and policy-based automatic IP blocking
Network access protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
Encrypted Access: HTTPS, FTP with SSL/TLS (Explicit), SSH/SFTP (admin only), encrypted remote replication between QNAP NAS servers (Rsync over SSH)
CIFS host access control for shared folders
Antivirus protection
FIPS 140-2 validated AES 256-bit volume-based data encryption*
AES 256-bit external drive encryption*
Importable SSL certificate
Instant alert via Email, SMS, Instant Messaging (Windows Live), Beep and LCD panel
Disk Management Single Disk, JBOD, RAID 0, 1, 5, 5+Hot-Spare, 6, 6+Hot-Spare, 10, 10+Hot-Spare
Online RAID capacity expansion and online raid level migration
Bad block scan and hard drive S.M.A.R.T.
Global hot-spare drive
RAID recovery
Bitmap support
iSCSI (IP SAN) iSCSI target
-Multi-LUNs per target
-Up to 256 targets/LUNs combined
-Supports LUN mapping and masking
-Online LUN capacity expansion
-Supports SPC-3 persistent reservation
-Supports MPIO and MC/S
iSCSI LUN backup, one-time snapshot and restore
iSCSI connection and management by QNAP finder (Windows)
Virtual disk drive (via iSCSI initiator)
-Stack chaining master
-Max. no. of virtual disk drives: 8
Server Virtualization and Clustering Supports VMware vSphere
Supports Citrix XenServer
Supports Windows Server 2008 R2 Hyper-V and failover clustering
Power Management Wake on LAN
Internal hard drive standby mode
Scheduled power on/off (max. 15 Settings)
Automatic power on after power recovery
USB and network UPS support with SNMP management
