Grandstream GWN7806P Dubai

Introducing the Grandstream GWN7806P Dubai, an advanced Layer 2+ network switch featuring an array of 48 RJ45 Gigabit Ethernet ports, each equipped with the capability of POE (Power Over Ethernet).

Ask for Quote & Get Low Price

Description

Grandstream GWN7806P Network Switch Dubai

Introducing the Grandstream GWN7806P Dubai, an advanced Layer 2+ network switch featuring an array of 48 RJ45 Gigabit Ethernet ports, each equipped with the capability of POE (Power Over Ethernet). This exceptional functionality enables the seamless connection and powering of an extensive range of devices, including VOIP phones, IP cameras, and more, all through a singular switch. Additionally, it incorporates six SFP+ ports designed for swift fiber connections. Operating as a POE switch, it boasts a substantial power budget of 400 W, facilitating the transmission of up to 30 W of power through Ethernet cables to the connected devices. The implementation of intelligent power control ensures that power allocation aligns precisely with the demands of the connected endpoint. This economically viable switch stands as an uncomplicated yet effective solution for establishing a high-caliber enterprise network.

The Grandstream GWN7806P Dubai operates as a managed network switch, effectively mitigating network congestion by furnishing Gigabit Ethernet connectivity to all linked devices. With an impressive total switching capacity of 216 Gbps, it ensures unhindered data flow. Primarily tailored for small-to-medium businesses, the switch introduces advanced VLAN and QoS capabilities, thereby facilitating the segmentation of traffic and optimizing overall network performance. The inclusion of an array of security features, including IP Source Guard and DoS protection, actively safeguards the network against malicious actors. Furthermore, the Grandstream GWN7806P Dubai offers the convenience of stacking, with the ability to stack up to 16 compatible switches .

Grandstream GWN7806P Features

  • 48 Gigabit Ethernet ports and 6 Gigabit SFP+ ports
  • Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models
  • Supports deployment in IPv6 and IPv4 networks
  • Reliability features including fault detection, device protection, dual boot, dual system file redundancy, link aggregation, storm control, and more
  • ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
  • Embedded controller to manage switch; GWN.Cloud and GWN Manager, Grandstream’s cloud and  on-premise Wi-Fi management platform
  • Built-in QoS allows for prioritization of network traffic
  • Supports stacking for easy management of up to 16 switches in one interface while creating redundant backup between multiple devices

Product Highlights

Powerful Processing Capabilities

Grandstream GWN7806P Dubai Layer 2+ managed network switch comes with powerful processing capabilities to ensure a high-performance backbone for any network.

  • Unicast routing via ACL for data communication routing between different network segments. Supports DHCP Server and Relay to assign IP addresses to hosts within the network.
  • GVRP for VLAN dynamic distribution, registration, and attribute propagation, to reduce the amount of manual configuration and ensure the correctness of configuration.
  • QoS, including Port Priority, Priority Mapping, Queue Scheduling, Traffic Shaping, and Rate Limit.
  • ACL is used to recognize the filtering of data packets by configuring matching rules, processing operations and time schedule, and providing flexible security access control policies.

Specifications

Network Protocol

IPv4, IPv6, IEEE 802.3, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af/at, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x

Gigabit Ethernet Ports

48

Gigabit SFP Ports

6

PoE Ports (PoE Models Only)

48

Total PoE Output Power (PoE Models Only)

400W (30W per Port)

Total Non- Blocking Throughput

108Gbps

Switching Capability

216Gbps

Forwarding Rate

160.704Mpps

Switching

  • 32K static, dynamic and filtering MAC addresses
  • 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN
  • VLAN virtual interface
  • GVRP (pending)
  • 27 link aggregation
  • Spanning tree, 64 instances for STP/RSTP/MSTP Routing Static

Security

  • User hierarchical management and password protection, HTTPS, SSH,Telnet
  • 802.1X authentication
  • AAA authentication including RADIUS, TACACS+
  • Storm control
  • Port isolation, port security, sticky MAC
  • Filtering MAC address
  • IP source guard, DoS attack prevention, ARP inspection,
  • DHCP Snooping
  • Loop protection including BPDU protection, root protection(pending), and loopback protection(pending)
  • Kensington Security Slot (Kensington Lock) support
