Barco ClickShare CS-100 Huddle Dubai


Barco ClickShare CS-100 Huddle Dubai

Barco ClickShare CS-100 Huddle Dubai, the Wireless presentation system for huddle spaces helps you to Collaborate better in small teams. Huddle spaces are creative, flexible, straightforward and intuitive spaces where you bring your own device to share, discuss, interact. ClickShare CS-100 Huddle wireless presentation system Dubai designed for spontaneous collaboration in huddle spaces, users can simply share what’s on their laptop or mobile device, on the presentation screen. No cables, no set-up, no waiting to join in. Focus on what matters.

Ask for Quote & Get Low Price


Barco ClickShare CS-100 Huddle Dubai

The Barco CS-100 Huddle Dubai brings quick, creative content sharing to small meeting and huddle rooms. It provides your enterprise with a uniform meeting experience from huddle space to the boardroom. Anyone including guests can connect and share, no need for training. Use the ClickShare App to get the content from your device on the meeting room screen. Make sure to have the latest firmware installed on your Base Unit to enable the best experience with the Desktop App. Or order the ClickShare Button in addition to the package for enriched, straightforward content sharing. The CS-100 Huddle Dubai is a product created with ISO 27001 certified flows and processes. Adding ClickShare CS-100 Huddle Dubai to your fixed conference room set-up (like a Microsoft Teams or Zoom room) enhances collaboration in your Microsoft Teams and Zoom meetings. It brings the focus from conferencing back to truly collaborating.

The ClickShare CS-100 Huddle Dubai is a stand-alone model with an HDMI output, that allows up to 8 users to connect and, with one user sharing at a time. It can also be integrated into the company network and centrally managed, to enjoy a uniform experience from your huddle space to your boardroom. The CS-100 Huddle Dubai includes the standard ClickShare security features including encryption, login management, HTTPS and the possibility to hide the SSID of the Base Unit’s wireless network.

Barco ClickShare CS-100 Huddle Specifications

ClickShare Base Unit dimensions

  • Weight: 600g / 1.32lbs
  • Dimensions (HxWxD): 205mm x 115mm x 45mm (Min.) / 8.1” x 4.5” x 1.8” (Min.)
  • Power consumption: Operation: 6W (typical) / 18W (max), Standby: 2.6W (ECO standby) / 0.4W (Deep standby)

General specifications

  • Operating system:
    • Windows 7/8/8.1/10 32 & 64 bit
    • macOS 10.14/10.15 (Catalina)
    • Android 9 & 10 (ClickShare app)
    • iOS 11, 12 & 13 (ClickShare app)
  • Video outputs: 1x HDMI 1.2
  • Output resolution: 1920×1080 @60Hz
  • Audio: Via HDMI, analogue via Audio Jack 3.5mm
  • Frame rate: Up to 30 fps*
  • Number of sources simultaneous on-screen: 1
  • Number of simultaneous connections: 8
  • iPad, iPhone and Android compatibility: Sharing of documents, browser, camera for both Android and iOS devices via ClickShare app
  • Extended desktop: Available for Windows, requires ClickShare Extension Pack.
  • Authentication protocol: WPA2-PSK in stand-alone mode WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode
  • Wireless transmission protocol: IEEE 802.11 a/g/n
  • Reach: Adjustable with signal strength modulation; max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit
  • Frequency band: 2.4 GHZ and 5 GHz (DFS channels not supported)
  • Connections:
    • 1x Ethernet LAN 100Mbit,
    • 1x (back) + 1x (front) USB
    • Audio analog line out on mini jack socket (3.5mm)
  • Noise Level: Fanless
  • Temperature range:
    • Operating: 0°C to +40°C (+32°F to +104°F),Max: 35°C (95°F) at 3000m
    • Storage: -20°C to +60°C (-4°F to +140°F)
  • Humidity:
    • Storage: 0 to 90% relative humidity, non-condensing
    • Operation: 0 to 85% relative humidity, non-condensing
  • Anti-theft system: Kensington lock
  • Certifications: FCC/CE
