• Superior Processing Power
  • The Ubiquiti UAP-IW-HD Dubai is capable of complex operations (guest control, filtering, and other resource-intensive tasks) that may slow down a lesser-equipped AP.
• Power over Ethernet (PoE) Standard
  • The UAP-IW-HD can be conveniently powered by an 802.3af or 802.at compliant switch. We recommend powering your UniFi devices with a UniFi PoE Switch.
• Customizable with Various Skins
  • Optional skins (sold separately) allow the Ubiquiti UAP-IW-HD Dubai to discreetly blend into its setting.
• UniFi Network application
  • Use the UniFi Network application to provision thousands of UniFi APs, map out networks, quickly manage system traffic, and provision additional UniFi APs.
• Quick and Simple Installation
  • The UAP-IW-HD Dubai has a refined industrial design and can be easily installed using the included mounting hardware.

Ubiquiti UAP-IW-HD Dubai Specifications

Physical Characteristics

• Dimensions: 139.7 x 86.7 x 25.75 mm (5.5 x 3.41 x 1.01″)
• Weight: 210 g (7.41 oz)
• Networking Interface: 5 x 10/100/1000 Ethernet Ports
• Buttons: Reset
• Power Method:
  • 802.3af PoE
  • 802.3at PoE+
• Supported Voltage Range: 44 to 57VDC
• PoE Out: 48V Passthrough (Pins +1, 2; -3, 6)
• Power Save: Supported
• Beamforming: Supported
• Maximum Power Consumption: 11W
• With PoE Passthrough: 23W
• TX Power:
  • 2.4 GHz: 23dBm
  • 5 GHz: 26 dBm
• Dual Band Antennas: 2 x Single-Port, Single-Polarity Dual-Band Antennas, 2.4 GHz: 1.8 dBi Each, 5 GHz: 3.4 dBi Each
• Single-Band: 2 x Single-Port, Dual-Polarity, Single-Band Antennas, 5 GHz: 6 dBi Each
• WiFi Standards: 802.11 a/b/g/n/ac/ac-wave2
• Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) 802.11w/PMF
• BSSID: Up to 8 per Radio
• Mounting: 1-Gang Electrical Wall Box (Not Included)
• Operating Temperature: -10 to 60° C (14 to 140° F)
• Operating Humidity: 5 to 95% Noncondensing
• Certifications: CE, FCC, IC

Advanced Traffic Management

• VLAN: 802.1Q
• Advanced QoS: Per-User Rate Limiting
• Guest Traffic Isolation: Supported
• WMM: Voice, Video, Best Effort, and Background
• Concurrent Clients: 200+

Supported Data Rates (Mbps)

• Standard: Data Rates
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
• 802.11ac: 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80)
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
